紅外分辨率 640 × 480 pixels

熱靈敏度/NETD <40 mK, 24° at 30°C (86°F)

<50 mK, 14° at 30°C (86°F)

精度 ±2°C (±3.6°F) or ±2% of the reading

視場角（FOV） 24° × 18°，14° × 10°

數碼相機 5 MP, with built-in LED photo/video lamp

顯示屏 4", 640 × 480 pixel touchscreen LCD with auto-rotation

存儲介質 Removable SD card

成像與光學

UltraMax（超級放大）功能 Yes

波長范圍 7.5-14 µm

調焦 Continuous LDM, One-shot LDM, One-shot contrast, Manual

調色板 Iron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava

非輻射紅外視頻流 H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi

輻射紅外視頻流 Yes, over UVC

輻射紅外視頻錄制 Real-time radiometric recording (.csq)

光圈數 24°: 1.3

14°: 1.3

紅外分辨率 640 × 480 pixels

畫中畫 Resizable and movable

焦距 24°: 17 mm (0.67 in)

14°: 29 mm (1.41 in)

鏡頭識別 Automatic

空間分辨率（IFOV） 24°: 0.67 mrad/pixel

14°: 0.38 mrad/pixel

取景器 No

熱靈敏度/NETD <40 mK, 24° at 30°C (86°F)

<50 mK, 14° at 30°C (86°F)

視場角（FOV） 24° × 18°，14° × 10°

數碼相機 5 MP, with built-in LED photo/video lamp

數字變焦 1-8× continuous

探測器類型與像素間距 Uncooled microbolometer, 12 µm

圖像頻率 30 Hz

***小焦距 24°: 0.18 m (0.59 ft), 14°: 1.0 m (3.28 ft)

***小焦距（帶MSX） 24°: 0.5 m (1.64 ft)

14°: 1.0 m (3.28 ft)

測量與分析

測量預設 No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2

測溫范圍 -20 to 120°C (-4 to 248°F); 0 to 650°C (32 to 1202°F); 300 to 1500°C (572 to 2732°F)

點溫儀 3 ea. in live mode

精度 ±2°C (±3.6°F) or ±2% of the reading

用戶界面

聲音 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth®

文本 Predefined list or touchscreen keyboard

顯示屏 4", 640 × 480 pixel touchscreen LCD with auto-rotation

電源

電池工作時間 >2.5 hours at 25°C (68°F) and typical use

電池類型 Rechargeable Li-ion battery

環境與認證

安全性 EN/UL/CSA/PSE 60950-1

存儲溫度范圍 -40 to 70°C (-40 to 158°F)

工作溫度范圍 -15 to 50°C (5 to 122°F)

常規

FLIR 檢測路線 Enabled in camera

包裝 Infrared camera with lens, s2 batteries, battery charger, hard transport case, lanyards, front lens cap, power supplies, printed documentation, SD card (8 GB), cables (USB 2.0 A to USB Type-C, USB Type-C to HDMI, USB Type-C to USB Type-C), License card: FLIR Thermal Studio Starter

激光指示器 Yes

形狀因數 Pistol
