| Number of Bus Terminals |
64 (255 with K-bus extension) |
| Max. number of bytes fieldbus |
512 byte input and 512 byte output |
| Digital peripheral signals |
1,020 inputs/outputs |
| Analog peripheral signals |
256 inputs/outputs |
| Protocol |
RTU/ASCII (default: RTU) |
| Configuration possibility |
by rotary switch or KS2000 |
| Bus interface |
D-sub 9-pin, RS485 |
| Power supply |
24 V DC (-15 %/+20 %) |
| Input current |
320 mA max. |
| Starting current |
2.5 x continuous current |
| Recommended fuse |
≤ 10 A |
| Current supply K-bus |
1750 mA |
| Power contacts |
max. 24 V DC/max. 10 A |
| Electrical isolation |
500 V (power contact/supply voltage/fieldbus) |
| Weight |
approx. 100 g |
| Operating/storage temperature |
-25…+60 °C/-40…+85 °C |
| Relative humidity |
95 %, no condensation |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. |
IP20/variable |
| Approvals/markings |
CE, UL, ATEX, IECEx |
| Ex marking |
ATEX:
II 3 G Ex nA IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc |
