PDPS系列 經濟型微差壓開關-德威爾Dwyer
PDPS系列 經濟型微差壓開關采用了大尺寸的隔膜片和快開開關，穩定可靠，常用于OEM設備制造中。PDPS系列差壓開關可以監測正壓，負壓和差壓，工廠在出廠時預設的設定點值在0.07英寸水柱到1.0英寸水柱之間，可重復精度為0.02英寸水柱。PDPS另外還帶有：適配多種軟管的接頭，固定安裝和快速插拔的接線頭，這些都特別適合在OEM設備中應用。
注意：訂購數量必須是50只或以上
Service: Air and Compatible gases.
Wetted Materials: Polyphenylene oxide-styrene housing, Florosilicon diaphragm, Stainless Steel spring.
Temperature Limits: -40 to 185°F (-40 to 85°C).
Operating Pressure: 0.07 in w.c. to 1.0 in w.c.
Repeatability: ±0.02 inches of w.c.
Burst Pressure: 3.5 psi (0.241 bar).
Proof Pressure: 1.0 psi (0.069 bar).
Switch Type: Conventional snap action switch.
Electrical Rating: 5A @ 125/250 VAC.
Process Connections: Multi-barb port connections for 1/4" and 3/8" ID tubing.
Mounting Orientation: Mount switch with diaphragm in a vertical position unless customer has specified otherwise.
Set Point Adjustment: Set point adjusted at factory.
Weight: 2.7 oz (76.5 g).
